OPERATING INSTRUCTIONS FOR GAMBIT DE-ESSER/COMPRESSOR DS1-MK3 FRONT PANEL
Weiss Engineering Ltd., Florastr. 42, CH-8610 Uster Page 4
+41 44 940 20 06 +41 44 940 22 14 http://www.weiss.ch [email protected]
Front Panel Groups
The front panel of the DS1-MK3 offers several control and display features.
Control
Refer to Graphic 1: Front Panel Elements
- Menu- and softkeys p. 7
- Snapshot keys p. 19
- ganged / channel select keys p. 16
- Gain / Data controller p. 8
- Crossover controllers p. 12
- Envelope follower controllers p. 10
+
- Non-linear transfer curve controllers p. 11
Display
Refer to Graphic 2: Display Elements
- Gain value p. 8
- Crossover setting (frequency selective mode only) p. 12
- Non-linear transfer curve and signal metering p. 11
- Status display p. 7
- Peak limiter gain reduction meter p. 8
- Envelope follower settings p. 10
- Compressor gain reduction meters p. 10
