OPERATING INSTRUCTIONS FOR GAMBIT DE-ESSER/COMPRESSOR DS1-MK3

TECHNICAL DATA

Weiss Engineering Ltd., Florastr. 42, CH-8610 Uster

Page 33

+41 44 940 20 06 +41 44 940 22 14 http://www.weiss.ch

[email protected]

Addendum to the Manuals of the Gambit Series DS1,

DS1-MK2 and DS1-MK3 DeEsser / Compressor / Limiter

The graphs on the pages below have been made to convey a better understanding of the dynamic pa-
rameters of the Gambit DS1 DeEsser/Compressor.

Please also read the appropriate pages in the DS1/DS1-MK2/DS1-MK3 manual to have a proper under-
standing of the sidechain process.

The test signal is a repeating sine wave burst with a certain "on" and a certain "off" level. The frequency
of the sine wave is above 10kHz (period less than 100µs), so there is no influence of the sine wave fre-
quency on the timing behaviour.

The table below shows the timing parameters set on the DS1. For the static parameters a threshold of -
20dB, a 1000:1 ratio and no softknee have been chosen. The peak / RMS time parameter was set to peak
measurement.

Figure

Preview

Attack

Rel.Delay

Rel.Fast

Average

Rel.Slow

burst duty cycle

1

bypass

2

20µs

20ms

20µs

200ms

800ms

1s

50%

3

63ms

"

"

"

"

"

"

4

"

"

"

"

"

200ms

"

5

"

"

5ms

"

"

"

"

6

"

"

20ms

"

"

"

"

7

"

"

"

25ms

"

500ms

0.5%

8

"

"

"

"

"

"

2%

9

"

"

"

"

"

"

5%

10

"

"

"

"

"

"

10%

11

"

"

"

"

40ms

"

0.5%

12

"

"

"

"

"

"

2%

13

"

"

"

"

"

"

5%

14

"

"

"

"

"

"

10%
