Specifications, Parts, Accessories, Dimensions, cont’d
SCP 150 • Specifications, Parts, Accessories, Dimensions SCP 150 • Specifications, Parts, Accessories, Dimensions
SCP 150 L
6.5"
(16.5 cm)
Cut-Out Template for Extron's SCM-150L
TEMPLATE IS NOT FULL SIZE.
To install SCP 150
directly into furniture,
cut along this line.
Top Panel
2.85"
(7.2 cm)
3.6"
(9.15 cm)
SURFACE CUT-OUT AREA
FOR FURNITURE MOUNT
3.15"
(8.0cm)
Location of SCP 150
A-9
2.
8
"
(7.1 cm)
E
lectr
ical Bo
x
SCP 150 AAP
TEMPLA
TE IS
NO
T
FULL SIZE.
T
o
p P
a
nel
Cut-Out T
emplate f
or Extron's
SCP 150 AAP
T
o
install SCP 150
directl
y into furniture
,
cut along this line
.
7.2"
(1
8
.3 cm)
SURF
A
CE CUT
-OUT AREA
FOR FURNITURE MOUNT
A-8
