SCP 150 • Remote Communication SCP 150 • Remote Communication
Remote Communication, cont’d
3-6 3-7
Command/response table for SIS commands (continued) Command
ASCII (T
elnet)
Response
Additional
(host to SCP)
(SCP to host)
information
V
olume relative function V
olume up
+V/v
V
olUp
V
olume down
-V/v
V
olDn
Upload firmware
Upload firmware
Esc
Upload
G
o
When you receive the Go response, upload the firmware according to your terminal emulator
’s
pr
ocedur
e.
{Specified number of bytes of data}
U
p
l
When upload is complete, you receive the Upl
response.
Reset to default settings (Zap command)
Reset to factory defaults
Esc
zXXX
ZapX
Sets all button LEDs to amber
. Special Function SIS Commands
The syntax for setting a special function for an SCP 150 is X? * Y? * __ #,
where X? is the value of the action to be performed, Y? is the value for
the button or switch, and __ is the function number. To view a
function’s setting, use __#, where __ is the function number. In the
following table the values of the
X? and Y? variables are different for
each command/function. These values are given in the rightmost
column.
