Specifications, Parts, Accessories, Dimensions, cont’d
SCP 150 • Specifications, Parts, Accessories, Dimensions SCP 150 • Specifications, Parts, Accessories, Dimensions A-7
Templates
The templates are not to scale and are provided for
reference only.
SCP 150
Cut-Out Template for Extron's SCP 150
TEMPLATE IS NOT FULL SIZE.
To install SCP 150
directly into furniture,
cut along this line.
Top Panel
Electrical Box
2.8"
(7.1 cm)
3.6"
(9.15 cm)
SURFACE CUT-OUT AREA
FOR FURNITURE MOUNT
Location of SCP 150
A-6
2X .380
1.710 2.770
2X .250
1.625
2.250
4.875
2.755
Ø
.219 .392 X 82°
3X
Ø
.120
.220 X 82°
MARKED F
0.100
E E
E E
F
F
F
2X 6.250
4X
Ø
.156 .290 X 82°
MARKED E
2X 2.855
3.150
2X .295
.000
.000
6.500
W
Ø
W
Ø
W
Ø
SCP 150 L
