SCP 150 • Specifications, Parts, Accessories, Dimensions SCP 150 • Specifications, Parts, Accessories, Dimensions
Specifications, Parts, Accessories, Dimensions
A-3 A-2
Control/remote — control pad
Serial control port ........................ RS-232, via a 3.5 mm captive screw
connector, 3 pole
Baud rate and protocol ............... 9600 baud, 8 data bits, 1 stop bit, no parity
Serial control pin configurations A = TX, B = RX, C = GND
IR remote control ........................ IR 402 (optional)
30' maximum, 40 degrees off axis
Program control .......................... Extron’s Simple Instruction Set (SIS ™ )
General
Power ............................................ 12 VDC, at 0.5 A, from the System 5 IP
switcher
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) /
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
Rack mount .................................. No, but furniture/wall mountable with
included faceplates and electrical boxes or
optional mounting bracket kits or AAP wall
plates.
Enclosure type .............................. Metal
Enclosure dimensions
SCP 150 faceplate ............. 4.5" H x 4.6" W x 0.1" D (2 gang)
11.4 cm H x 11.7 cm W x 0.3 cm D
SCP 150 AAP faceplate .... 4.5" H x 8.25" W x 0.1"D (4 gang)
11.4 cm H x 11.7 cm W x 0.3 cm D
SCP 150 L faceplate .......... 3.2" H x 6.5" W x 0.1"D
8.0 cm H x 16.5 cm W x 0.3 cm D
Circuit board (all models) 2.9" H x 3.5" W x 0.5" D
7.4 cm H x 8.9 cm W x 1.3 cm D
[Allow at least 1.5" (3.8 cm) depth in the
wall or furniture. Depth excludes
connectors, knob, and buttons.]
Product weight ............................. 0.3 lbs (0.1 kg)
Shipping weight ........................... 2 lbs (1 kg)
Vibration ....................................... ISTA 1A in carton (International Safe
Transit Association)
Listings .......................................... UL, CUL as a component of the System 5 IP
Compliances ................................. CE as a component of the System 5 IP
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
Included Parts
These items are included in each order for an SCP 150,
SCP 150 AAP, or SCP 150 L:
Replacement
Included parts part number
SCP 150 (controller only - no faceplate) 60-495-00
SCP 150 (gray, black, white, RAL9010) 60-495-01, -02, -03, -05
SCP 150 AAP (gray, black, white, RAL9010)
60-496-01, -02, -03, -05
SCP 150 L (black, white, RAL 9010) 60-495-32, -33, -35
3.5 mm, 5-pole captive screw connector (2) 10-319-01
3.5 mm, 3-pole captive screw connector (1) 10-265-03
Button labels (text) 33-954-01
Button labels (symbols) 33-955-01
International faceplate labels
(gray, black, white) 33-953-01, -02, -03
Tweeker (small screwdriver)
SCP 150 User’s Manual
