10

GB

3. Drill two holes into the worktop

(22).

4. Using the enclosed screws (23),

washers and nuts (24), screw the

grinding plinth in place on the

worktop.

Assembling the grinder:

5. Screw the handle (4) into the

grinding head (2).

6. Remove the locking screw (10)

from the chain clamping unit (12).

7. Place the chain clamping unit (12)

on the grinding plinth (8) and fix it

using the locking screw (10).

8. Snap the mains lead (17) into the

cable hook (16).

Screwing on the adjusting

screw:

9. Place the enclosed washer (25) on

the adjusting screw (6).

10. Screw the adjusting screw (6) onto

the securing nut (26) fixed into the

grinding head (2).

Operation

Working with the equipment

Caution! Risk of injury!

- Use only grinding disks and acces-

sories recommended by the manu-

facturer. The use of other insertion

tools and other accessories may

cause risk of injury.

- Never operate the device without

the visual protection disk.

- Do not use saw blades.

- Check the grinding disk before

use: check the distance between

the protective screen and the grind-

ing disk.

- Do not use broken, cracked or oth-

disk. This will cause a risk of crushing.

• The chain becomes hot during grind-

ing. Do not touch the machined loca-

tion, as there is a risk of being burnt.

• Use only grinding disks recommended

by the manufacturer. Do not use saw

blades.

• Switch off the device and disconnect at

the plug

- to release a jammed insertion tool,

- if the connecting cable is damaged

or tangled,

- in the case of unusual noises.

Installation

Always use the M10x70 screws

from the package to mount the unit.

Make sure to leave enough

room for working and that

nobody else is put at risk.

Always use screws of suf-

ficient length and thickness

to mount the device on the

work surface, in order to

prevent loss of control of the

device.

Installing the appliance:

- Thickness of the table edge:

15 - 30 mm.

- Drill diameter: 10.5 mm.

- Size of screw: M10

1. Use the stop notches (9) to cor-

rectly place the appliance on the

worktop (22). Make sure that the

grinding plinth (8) protrudes be-

yond the edge of the table.

2. Use a pen to mark the drill holes

and remove the appliance.
