PETROL GRASS TRIMMER FBS 43 B2
Introduction
Congratulations on the purchase of your new device. You have selected
a high-quality product. The operating instructions are an integral part of
this product. They contain important information about safety, use and
disposal. Before using the product, familiarise yourself with all operating
and safety instructions. Use this product only as described and only for the
specifi ed areas of application. Please also pass these operating instructions
on to any future owner(s).
Proper use
Use with cutting blade: for cutting high grass and undergrowth with the
4-section cutting blade, or dense undergrowth and small woody plants
with the 3-section cutting blade.
Use with line spool: for cutting grass and small weeds.
Any other use which is not expressly permitted in these operating instructions
may damage the device and represents a serious risk for the user. Please
make sure that you pay attention to the restrictions in the safety instructions
Pay attention to the national regulations which may restrict the use of the
machine. Any other uses of or modifi cations to the device are deemed to
be improper usage and may result in serious physical injury. Not intended
for commercial use.
PROHIBITED APPLICATIONS!
Due to the physical risk posed to the user, the device may not be used to
perform the following activities: cleaning footpaths and as a shredder for
shredding tree and hedge sections. Furthermore, the device may not be
used to level elevations such as molehills. For reasons of safety, the device
may not be used as a drive unit for any other devices. The user, not the
manufacturer, is liable for any resulting damage or injuries of any kind.
Package contents
1 petrol grass trimmer FBS 43 B2
1 operating instructions
■ Open the packaging and carefully remove the device.
■ Remove the packaging material and packaging and transport locks
(if present).
■ Check to ensure that the package content is complete.
■ Inspect the device and accessories for transport damage.
■ If possible, store the packaging until the end of the warranty period.
Features
Guide rail connecting piece
Guide rail
Guide handle
Starter pull cord
Choke lever
Fuel tank
Fuel pump (primer)
Air fi lter housing cover
On/Off switch
Throttle control
Throttle control lock
Line spool with cutting line
Cutting line protective hood
Cutting blade protective hood
2 x M6 screws
Shoulder strap
4-tooth cutting blade
3-tooth cutting blade
Handle bracket
M6 handle screw
Drive plate
Pressure plate
Pressure plate cover
M10 nut (left-hand thread)
Oil/petrol mixing canister
Spark plug spanner
5 mm hexagonal key
4 mm hexagonal key
M6 handle screw
Air fi lter
Spark plug connector
The cutting blade / and line spool are also referred to together
as the cutting tool in the text.
