52

GB MT

General description

The illustration of the princi-

pal functioning parts can be

found on the front and back

foldout pages.

Extent of the delivery

Carefully unpack the appliance and check

that it is complete.

Dispose of the packaging material cor-

rectly.

- Appliance

- Grass trimming blade + blade guard

- Shrub trimming blade + blade guard

- Telescopic shaft

- Wheels on a shaft

- Recharger

- Instruction Manual

Function description

The battery-powered grass and bush trimmer

is a combination unit with two interchange-

able cutting devices. These are coated with

plastic (Teflon non-stick coating) to prevent

rust. For use as a shrub trimmer, a double-

sided blade block is used as the cutting

head. When cutting, the blades oscillate lin-

early against an unsharpened cutting plate.

The catching blades are round off at the

side to prevent accidents, and positioned in

an offset arrangement to reduce the risk of

injury. A cutting head with several blades

is provided for use as a grass trimmer. This

also oscillates on a bladed plate, producing

the same movement as a pair of scissors.

The unit is equipped with a telescopic shaft

and rollers for increased working speed

and comfort. Please read the following

descriptions for the function of the various

controlling parts of the unit.

Overview

Appliance:

1 Cutting head

2 Off-lock switch, unit

3 Unit handle

4 Charge display (LED)

5 Charging socket + plug socket

for telescopic shaft

6 On/off switch, unit

7 Unlock button

Cutter:

8 Blade guard for grass trimming

blade

9 Grass trimming blade

10 Blade guard for shrub trimming

blade

11 Shrub trimming blade

Telescopic shaft with rollers:

12 Off-lock switch, telescopic shaft

13 Handle

14 On/off switch, telescopic shaft

15 Telescopic tube

16 Plug connection

17 Height adjustment screw

18 Rotary joint for turning the tel-

escopic shaft

19 Equipment holder

20 Wheels on a shaft

Recharger:

21 Power supply unit

22 Recharger cable plug

23 Blade drive
