Gaining Access to Memory Modules
B-12 Mode Switch Settings and Option Installations
Reinstalling the Optional Network Expansion Module
Refer to
1.
Position the NEM so its front panel is under the edge of the DFE module front panel.
2.
Align the two NEM connectors with the main board connectors. Then press straight
down over the two NEM connectors, applying pressure until they are properly
seated.
Figure B-9 Installing the Network Expansion Module
3.
Use two of the saved coverplate screws to fasten the NEM to the DFE‐Gold module
front panel, but do not tighten screws at this time.
4.
Insert the saved standoff through the NEM to the standoff on the main board. Screw
in the standoff, but do not tighten screws at this time.
5.
Tighten the two coverplate screws first, then the standoff.
1 NEM
3 NEM connectors
5 Coverplate screws (2)
2 Front panel
4 Main board connectors
6 Standoff
