COM Port Pinout Assignments
Matrix DFE-Gold Series PoE Module Hardware Installation Guide A-3
COM Port Pinout Assignments
The COM port is a serial communications port for local access to Local Management.
Refer to
for the COM port pin assignments.
Regulatory Compliance
The 4H4285‐49, 7G‐6MGBIC, and 7G‐6MGBIC‐A meet the safety and electromagnetic
compatibility (EMC) requirements listed in
:
Table A-2 COM Port Pin Assignments
Pin
Signal Name
Input/Output
1
Transmit Data (XMT)
Output
2
Clear to Send (CTS)
Input
3
Data Set Ready (DSR)
Input
4
Receive Data (RCV)
Input
5
Signal Ground (GND)
NA
6
Request to Send (RTS)
Output
7
Data Terminal Ready (DTR)
Output
8
Data Carrier Detect (DCD)
Input
Table A-3 Compliance Standards
Regulatory Compliance
Standards
Safety
UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN
60950, IEC 60950, EN 60825, 21 CFR 1040.10.
Electromagnetic Compatibility (EMC)
47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN
55022, EN 61000-3-2, EN 61000-3-3, EN 55024, AS/
NZS CISPR 22, VCCI V-3.
