Controlling the SD-80 via MIDI
If
MFX type=18:Mod Delay
is applied to the sound of part 3 and you want to change its
DLY Right
setting (parameter number 02) to
80
(=50H), transmit the following system exclusive data.
1. F0 41 10 00 48 12 11 40 06 15 08 00 05 00 07 F7
When MFX source = COMMON
When MFX source = COMMON, transmit the following system exclusive data.
Address (p1 p2):
when editing MFX A’s parameter number 1 =06 11 (for MFX B =08 11, for MFX C =0A
11)
when editing MFX A’s parameter number 2 =06 15
:
when editing MFX A’s parameter number 3 =06 19
:
: (the address will increment by 04H each time the parameter number increases by 1)
when editing MFX A’s parameter number 29 =07 01 (for MFX B =09 11, for MFX C =0B
11)
when editing MFX A’s parameter number 30 =07 05
:
when editing MFX A’s parameter number 31 =07 09
:
when editing MFX A’s parameter number 32 =07 0D
:
Data
(d1, d2, d3, d4):
Effect parameter
The lower 4 bits of the four data bytes indicate a signed numerical value. For details on the data byte
expression, refer to
Checksum (ss):
For details on the calculation method, refer to the section
“How to calculate the
checksum”
within
“MIDI Implementation”
(MIDIImp_E.pdf) on the included CD-
ROM.
If MFX C COMMON is set to
MFX type=53:Od2
, and you want to change its
EQ Low Gain
(parameter
number 05) to
-3 dB
, transmit the following system exclusive data.
1. F0 41 10 00 48 12 10 00 0A 21 07 0F 0F 0D 13 F7
F0 41 10 00 48 12 [10 00 r1 r2] [d1 d2 d3 d4] [ss] F7
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
