RGB 500 Series • Installation and Operation
Installation and Operation, cont’d
RGB 500 Series
A
Appendix A
Specifications
Interface Specifications
Attaching the faceplate
1 . Attach the faceplate to the interface(s) using two 3/8”
(0.95 cm) long #4-40 machine screws (provided) per two-
gang size (four screws total for the RGB 500 Dual,
RGB 508, RGB 560 Dual and RGB 568). Use the illustration
on the opposite page as a guide.
2 . Insert the interface and attached cables into the opening in
the wall or furniture, taking care not to damage the cables.
3 . Attach the faceplate to the mounting bracket with four
3/8” (0.95 cm) long, #6-32 machine screws (provided). Use
the illustration on the opposite page as a guide.
4 . Reconnect the computer video and audio input cables and
(for the RGB 560 series and RGB 568 series) the local
monitor output cable to the interface.
5 . Adjust horizontal centering as needed.
2-18
