Single-Compressor Module

Compressor Module Nomenclature

iv

2008SSD-34 (5/11)

C

ompressor

m

odule

N

omeNClature

Model

Max

Delivery

Pressure

(PSIG)

Max

Flow

(MCFD)

Drive

HP

High

Press

Switch

Setting

(PSIG)

Low

Press

Switch

Setting

High

Temp

Setting

°F (°C)

Oil

Thermal

Bypass

Valve

Setpoint

°F (°C)

Gas

Bypass

Valve

Module

Weight

(Lbs.)

Single Scroll Units

SZO22C3A-EDE-234

125

100

10

215

2” W.C.

(5 mbarg)

240

(116)

200

YES

350

SZV22C1A-EDE-140

190

100

15

215

2” W.C.

(5 mbarg)

280

(138)

250

NO

356

NOTE:

SZO modules are intended for use with clean, dry gas in applications with moderate ambient

temperatures. Oil thermal bypass valve setpoint is 200°F. Most SZO module applications use

PAO oil.

SZV modules keep discharge gas temperatures elevated to help with dewpoint control. SZV

modules insulate the separators and use a 250°F oil thermal bypass valve. In cold ambient,

and SZV module should be used with an enclosure. Most SZV module applications use PAG

oil.

Refer to Copeland Scroll Gas Compression Module Performance Program for all details.
