Single-Compressor Module

Installation

2.6.6 Variable Frequency Drive (VFD) Terminations

Refer to Product Bulletin on Variable Frequency Drive Applications for details on VFD terminations

and typical VFD parameters.

3.0 o

peratioN

3.1 Initial Startup - Compressor Module

The following inspections should be made on initial startup—-typically, by the Packager—and after long

periods of storage.

• Verify acceptable pre-startup conditions using the checklist in

3.1.1 - Pre-Startup Checklist.

• Start the Compressor Module, then perform the checks in

3.1.2 - Post-Startup Checklist.

3.1.1 Pre-Startup Checklist

Perform these checks BEFORE starting the Compressor Module:

MAIN POWER

Check for the following conditions:

___ 1. Motor type is correct for the application,

either Variable Speed C3A or C2A motor.

___ 2. Power phasing to the terminal strip and

Compressors is correct.

___ 3. Supply voltage to the Variable Frequency

Drive (VFD) or Fixed Speed Compressor

motors is correct.

___ 4. All chassis, earth grounds are connected.

___ 5. A load reactor or other approved filter is

installed for systems with power lead lengths

in excess of 200 ft. (61m) between the VFD

and Compressor Module terminal box.

LOW VOLTAGE DEVICES

Verify these conditions for low voltage devices:

___ 1. DC polarity is correct.

___ 2. Temperature control device—if other than

standard thermistor control—is working

properly.

SAFETY AND CONTROL DEVICES

Make sure that all safety and control switches

and devices are configured to inhibit Compressor

operation if a fault condition is detected, including:

___ 1. Low inlet pressure switch

___ 2. High discharge pressure switch

___ 3. High temperature switch

___ 4. Variable Frequency Drive (VFD) fault

___ 5. Motor overload trip

___ 6. Other safety and control switches and

devices

MECHANICAL SYSTEMS

Inspect for these conditions:

___ 1.

(Required) Compressor inlet is protected

from water slugging.

___ 2.

(Recommended) Gas filtration and

treatment is appropriate for the

application.

___ 3. Packager configuration applies back

pressure to the Compressors.

___ 4. Inlet and discharge valves allow the

module to be isolated.

___ 5. All guards and protective covers are

installed.

___ 6. Protection from freezing is provided if

needed for the application and location.

___ 7. A suitable enclosure providing protection

from the elements is appropriate for the

application and location.
