Single-Compressor Module

Introduction

1.2 The Compressor

The

Compressor refers to the Copeland Scroll

®

Compressor.

Figure 2 shows a cross-section of a

Compressor and its key components.

Figure 2 Copeland Scroll

®

Compressor Cross Section (not shown: Encapsulated Stator)

1.3 The Compressor Package

The

Compressor Package consists of the Compressor Module housed in an assembly ready for service

in the field. Equipment

Packagers customize the assembly and complete the fabrication for Compressor

Modules for each application.

Figure 3 shows a simplified example of a Compressor Package.

Figure 3 Typical Compressor Package

Oil

cooler

Gas aftercooler

(if applicable)

Control and

power panel

Compressor

Module

Inlet gas scrubber

for liquid removal
