6. Maintenance
6.1.
Replacing the air filter
In dusty environments, the use of air filters is strongly recommended. If
used they should be replaced at least once a year.
6.2.
Replacing the fan unit
The fan unit, consisting of four fans and a fan plate, can be replaced. To
install a new fan unit, execute the steps outlined in Procedure 10 and
illustrated in Figure 11.
Figure 11 - Replacing the fan unit
