Functional description 43

Emerson Energy Systems

Rectifier 200I/48



NT5C05C Installation and User Manual

Table 14 - Control signal connections on P1 ( continued )

Connection Signal

Description

P1-11 NC

connection

P1-12 NC

connection

P1-13

CB OFF ( NC )

Output breaker OFF ( NC )

P1-14

RG+

Remote sense ( + )

P1-15 TR

Rectifier

temporary

released

controller

P1-16

HVSD

High voltage shutdown

P1-17

CURRENT SHARE

Forced share link

P1-18

RFA ( C )

Rectifier fail alarm ( C )

P1-19

SH+

Shunt ( + )

P1-20

FAN ( NO )

Fan fail ( NO )

P1-21 GRD

Reference

ground

P1-22

SENSE FAIL ( NC )

Sense fail alarm ( NC )

P1-23 NC

connection

P1-24 NC

connection

P1-25

CB OPEN ( C )

Output breaker OFF ( C )
