2. Lift the box up and away from the printer.
Remove all items from the hollow (A and B)
on the rear side of the printer.
Note:
The ink cartridges included with your printer are
primarily for initial setup.
3. Take out the cardboard panels from the
printer.
Mounting the printer on the base unit
1. Lock the two casters (J) and extend the two
stabilizer knobs (K) underneath the base unit.
Note:
Place the casters sideways and lock them so they
will not move.
2. Position the base unit in front of the printer
unit as shown.
3. Mount the printer on the base unit as shown
below.
c Caution:
Do not attempt to lift the printer unit with
fewer than four people.
Note:
When you place the printer on the base unit, match
the right end square of the printer (shown as 4 in
the illustration below) to the square of the same part
of the base unit.
J K
top view
