17375-6-0705

FBB4 OPTIONAL VARIABLE SPEED BLOWER INSTALLATION

110 VOLT AC

JUNCTION BOX

WHITE

SPEED

CONTROL

FAN

SWITCH

GROUND

BLACK

FAN

1

FBB4

BLOWER ASSEMBLY

COMPLETE

2

R7649

FAN CONTROL

3

R4192

SPEED CONTROL KNOB

4

R4186

SPEED CONTROL
