Page 46 17375-6-0705
INDEX NO. PART NUMBER DESCRIPTION
DVP42 DVP48
1 R-7654 R-7654 FLUE INSULATION
2 17426 17426 FLUE INSULATION RETAINER
3 R-7567 R-7567 INLET VENT ADAPTOR
4 R-7573 R-7573 INLET VENT GASKET
5 17363 17363 FLUE OUTLET ASSEMBLY
6 M170 M170 FLUE CONNECTOR GASKET
7 17142 17142 VENT COVER PLATE
8 R-7575 R-7575 VENT COVER PLATE GASKET
9 17430 17430 FLUE COVER PLATE
10 R-7574 R-7574 FLUE OUTLET GASKET
11 17247 17247 TOP STANDOFF (2 REQUIRED)
12 10554 10554 NAILING FLANGE (4 REQUIRED)
13 17162 17162 JUNCTION BOX ASSEMBLY
14 R-3492 R-3492 RECEPTICAL, 3 - PRONG
15 17357 17357 JUNCTION BOX SHIELD
16 17445 17446 TOP SHIELD
17 17804 17805 INNER TOP HEAT SHIELD
18 17381 17447 BAFFLE, FLUE VENT
19 17187 17210 LOUVER ASSEMBLY - UPPER
20 17190 17213 GLASS DOOR FRAME ASSEMBLY
21 17188 17211 LOUVER ASSEMBLY - LOWER
22a R-7532 R-7532 PILOT, SIT GAS (NAT)
22a R-7533 R-7533 PILOT, SIT GAS (LP)
22b R-5747 R-5747 PILOT, INTERMITTENT GAS (NAT)
22b R-5748 R-5748 PILOT, INTERMITTENT GAS (LP)
22c R-6116 R-6116 PILOT, RF GAS (NAT)
22c R-6117 R-6117 PILOT, RF GAS (LP)
23 M173 M173 PILOT GASKET
24 11269 11269 GAS LINE BRACKET
26 P200 P200 ORIFICE FITTING
27 P203 P213 ORIFICE (NAT)
27 P185+ P250 ORIFICE (LP)
28 R-5676 R-5676 AIR SHUTTER
29 11499 11499 BURNER BRACKET LEFT
30 11377 11377 BURNER BRACKET RIGHT
31 17370 17386 SLOPE BURNER
32 17368 17385 BURNER BASE PLATE ASSEMBLY
33 17369 17369 TUBING ASSEMBLY
34 R-2423+ R-2423+ MALE CONNECTOR
35 R-1109+ R-1109+ BUSHING, FLUSH TYPE (IP ONLY)
36a R-7577 R-7577 VALVE, SIT GAS (NAT)
36a R-7578 R-7578 VALVE, SIT GAS (LP)
36b R-5745 R-5745 VALVE, INTERMITTENT PILOT GAS (NAT)
36b R-5746 R-5746 VALVE, INTERMITTENT PILOT GAS (LP)
36c R-6114 R-6114 VALVE, RF GAS (NAT)
36c R-6115 R-6115 VALVE, RF GAS (LP)
37a 17161 17161 VALVE BRACKET (SIT)
37b 17795 17795 VALVE BRACKET (IP)
37c 17796 17796 VALVE BRACKET (RF)
38 16223 16223 SPRING LATCH ASSEMBLY
39a R-3435 R-3435 WIRING HARNESS (SIT)
39b R-5751 R-5751 WIRING HARNESS (IP)
40 R-2708+ R-2708+ PIEZO IGNITOR
41 R-3436+ R-3436+ REMOTE OFF/ON SWITCH
42 R-1995+ R-1995+ TRANSFORMER (IP)
43 R-5160 R-5160 TRANSFORMER CORD SET (IP)
44 R-1616+ R-1616+ CONTROL MODULE (IP)
45 R-721+ R-721+ WIRING ASSEMBLY (IP)
46 - - AIR DEFLECTOR (RF)
47 18858 18858 BLOWER BASE (RF)
48 R-7731 R-7731 BLOWER MOTOR ASSEMBLY (RF)
49 R-7831 R-7831 BLOWER CORD SET (RF)
50 R-7643 R-7643 TOP LOG - TWIG
51 R-7642 R-7642 REAR LOG
52 R-7641 R-7641 MAIN LOG
PARTS LIST
USE ONLY MANUFACTURER’S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
