Proper Usage of the
Veritas
™ Stand for V2.1
and V2.2 Models
The Veritas ™ Stand has been purpose built not only
to improve the looks of the Veritas ™ bookshelf models
V2.1 and V2.2, but also to place the speakers at the
optimum height.
The Veritas ™ speakers incorporate inserts into the speakers'
bottom, to allow physically attaching the speaker to the
stand for enhanced safety. Please follow the instructions in
this order.
1) Begin assembly of the stand, one by one, carefully
following the directions included in the stands'
packaging.
2) Decide if you wish to use filler material in the stands
before you complete the assembly process. Filler will
not only add weight to the stand, but mass, which
helps provide a solid foundation for the speaker. As
well, filler material helps eliminate resonances that can
transfer to the floor and “color” the resulting sound
from the speaker.
3) Complete the assembly of both stands.
4) Place the speaker on the stand.
5) Using the hardware supplied with the stand, attach
the speaker to it by inserting the two Philips head
bolts from the bottom of the stands' top plate into the
insert on the speakers' bottom. Hand tighten only!
6) The front bolt goes through the front hole on the
top plate, inserted from the bottom. Insert the bolt
into the speaker, the insert is situated in the middle
of the speakers' base. The second bolt inserts into
the semi-circular rear foot on the back of the speaker.
See Figure 2A.
7) Once both are in place, tighten them both with a
Philips screwdriver.
The speaker is now attached providing better stability,
better sound, and of course great looks! See Figure 2B.
OWNERS MANUAL VERITAS ™
7
FIGURE 2B
FIGURE 2A
