Design LED 60 TriStrip™
©Elation Professional, Los Angeles Ca. 10 www.ElationLighting.com
7. Power Output Jack – Use this jack to jump power to another Design LED 60 TriStrip™
8. 3-Pin DMX Output Jack – This jack is used to send an incoming DMX signal to the next
fixture in the DMX chain via a female, 3-pin XLR jack.
9. 3-PIN DMX Input Jack – This jack accepts an incoming DMX signal via a male, 3-pin
XLR jack.
10. LED Menu Display - 4-segment menu display. Used to display the DMX address as
well as all other menu functions.
11. 5-PIN DMX Input Jack – This jack accepts an incoming DMX signal via a male, 5-pin
XLR jack.
12. 5-Pin DMX Output Jack – This jack is used to send an incoming DMX signal to the next
fixture in the DMX chain via a female, 5-pin XLR jack.
13. MENU Button - This button is used to access the fixtures menu functions.
14. Up Button – The up button is used to toggle forward through the menu functions and
settings.
15. Down Button – The down button is used to toggle backwards through the menu
functions and settings.
16. Enter Button – The enter button is used to enter in to a certain menu function or to lock
a menu setting in to memory.
17. Cooling Fans – These fans regulate the internal operating temperature of the fixture. To
prevent overheating or failure be sure to never block or obstruct these fans in any way.
