Eiki LC-NB3E User Manual
Page 56
MM8-NB3E00
Electrical Parts List
-56-
●
OUT OF CIRCUIT BOARD
F601
Fuse
Power Board
Thermal Switch
(SW902)
Note: Parts order must contain Chassis No., Part No., and Descriptions.
AV Sub Board
FN906
Cooling Fan
P.F. Board
FN901
Cooling Fan
Interlock switch
(SW904)
Temp Board
RC Board
AV Board
Main Board
Line Filter
Board
Lamp Ballast
Unit
