Eiki LC-NB3E - Manual (Page 33)

11 AV Cinema Green 32 0 ~ 63
12 AV Cinema Blue 32 0 ~ 63
13 AV Cinema Sharpness 15 0 ~ 31
14 AV Cinema Gamma 8 0 ~ 15
Group: 500 ADC
0 ADC R-OFFSET 64 0 ~ 255
1 ADC G-OFFSET 64 0 ~ 255
2 ADC B-OFFSET 64 0 ~ 255
3 ADC R-GAIN 254 0 ~ 255
4 ADC G-GAIN 254 0 ~ 255
5 ADC B-GAIN 254 0 ~ 255
Group: 510 NTSC Gakaku
0 NTSC TOTAL DOTS 2054 0 ~ 2047
1 NTSC DISP DOTS 800 0 ~ 2047
2 NTSC H BACK PORCH 180 0 ~ 2047
3 NTSC V BACK PORCH 46 0 ~ 2047
4 NTSC DISP LINE 456 0 ~ 2047
5 NTSC CLAMP 4 0 ~ 2047
Group: 511 PAL Gakaku
0 PAL TOTAL DOTS 2102 0 ~ 2047
1 PAL DISP DOTS 800 0 ~ 2047
2 PAL H BACK PORCH 207 0 ~ 2047
3 PAL V BACK PORCH 62 0 ~ 2047
4 PAL DISP LINE 533 0 ~ 2047
5 PAL CLAMP 4 0 ~ 2047
Group: 512 HDTV 1080i-60 Gakaku
0 TOTAL DOTS 942 0 ~ 2047
1 DISP DOTS 800 0 ~ 2047
2 H BACK PORCH 115 0 ~ 2047
3 V BACK PORCH 52 0 ~ 2047
4 DISP LINE 1048 0 ~ 2047
5 CLAMP 5 0 ~ 2047
Group: 513 HDTV 1080i-50 Gakaku
0 TOTAL DOTS 1130 0 ~ 2047
1 DISP DOTS 800 0 ~ 2047
2 H BACK PORCH 113 0 ~ 2047
3 V BACK PORCH 64 0 ~ 2047
4 DISP LINE 1044 0 ~ 2047
5 CLAMP 5 0 ~ 2047
Group: 514 HDTV 1035i Gakaku
0 TOTAL DOTS 942 0 ~ 2047
1 DISP DOTS 800 0 ~ 2047
2 H BACK PORCH 115 0 ~ 2047
3 V BACK PORCH 90 0 ~ 2047
4 DISP LINE 1006 0 ~ 2047
5 CLAMP 5 0 ~ 2047
Group: 515 HDTV 720p Gakaku
0 TOTAL DOTS 1060 0 ~ 2047
1 DISP DOTS 800 0 ~ 2047
2 H BACK PORCH 206 0 ~ 2047
3 V BACK PORCH 36 0 ~ 2047
4 DISP LINE 698 0 ~ 2047
5 CLAMP 5 0 ~ 2047
Group: 516 HDTV 575p Gakaku
0 TOTAL DOTS 1052 0 ~ 2047
1 DISP DOTS 800 0 ~ 2047
2 H BACK PORCH 188 0 ~ 2047
3 V BACK PORCH 60 0 ~ 2047
4 DISP LINE 524 0 ~ 2047
5 CLAMP 0 0 ~ 2047
Group: 517 HDTV 480p Gakaku
0 TOTAL DOTS 1006 0 ~ 2047
1 DISP DOTS 800 0 ~ 2047
2 H BACK PORCH 167 0 ~ 2047
3 V BACK PORCH 46 0 ~ 2047
4 DISP LINE 451 0 ~ 2047
5 CLAMP 0 0 ~ 2047
No. Adjustment Item Initial Value Range Description
-33-
Electrical Adjustments
