Eiki LC-NB3E User Manual
Page 11
-11-
1
Remove 4 screws
A
to take the Fan(FN901) off.
2
Remove 4 screws
B
to take the Fan(FN905) off.
3
Remove 3 screws
C
to take the Power Box Cover upward off.
Mechanical Disassemblies
1
Remove 1 screw
A
to take the Lamp Cover off.
2
Loosen 3 screws
B
to take the Lamp assembly by
pulling the handle.
Step to next procedure.
Fig.8
-1
Fig.7
Power Box Cover and Fans(FN901, FN906) removal
7
Optical Unit removal
8
-1
A
A
A
A
B
B
B
B
C
C
C
FN901
FN906
Power box cover
Lamp cover
Lamp ass’y
A
B
B
B
