13 EN
Preparation
1
Charging and inserting the battery
1 Charging the battery.
Charging indicator
Charging in
progress
Lights orange
Charging
complete
Off
Charging error Blinks orange
(Charging time: Up to
approximately 3 hours 30 minutes)
1
2
3
AC wall outlet
Lithium ion battery
Charging
indicator
AC cable
Direction indicating
mark (C)
Lithium ion
charger
• Unplug the charger when charging is complete.
2 Opening the battery/card
compartment cover.
Battery/card compartment lock
Battery/card compartment cover
1
2
3 Loading the battery.
Direction indicating
mark
Removing the battery
Turn off the camera before opening or closing the
battery/card compartment cover. To remove the
battery, fi rst push the battery lock knob in the direction
of the arrow and then remove.
• Contact an authorized distributor or service center if you are unable to remove the
battery. Do not use force.
• It is recommended to set aside a backup battery for prolonged shooting in case the
battery in use drains.
• Also read “Battery and charger” (P. 123) .
