1
Introduction
Chapter 1
Network Application Platforms
Chapter 1:
Introduction
Thank you for choosing the FW-8893/FW-8893C. The FW-
8893/FW-8893C is a 1U platform which features dual Intel
Xeon E5-2600 coupled with cave creek PCH. It features
many major advanced technologies as the following
stated:
2nd Generation Intel Xeon E5-2600/E5-2600 v2 •
Processor family for the LGA 2011:
The motherboard supports up to 2 CPU configurations
(and up to 8 cores per CPU) in the latest 2nd generation
Intel E5-2600 processor in the LGA 2011 package. This
new CPU also comes with the newest PCIe 3.0 bus
standard.
Intel Cave Creek/Coleto Creek Platform Controller
•
Hub:
The built-in Intel QuickAssist technology on the
Coleto Creek/Cave Creek chipset provides bulk data
encryption/decryption using AES, 3DES or (A)RC4
algorithms and hash using MD5, SHA-1/2 and HMAC
algorithms and pattern matching. The chipset will
also support Intel Virtualization Technology.
Quad-Channel DDR3 DIMM support:
•
The motherboard supports DDR3 memory that
features quad-channel memory configurations in 16
DIMMs.
4 pairs of Lanner Generation 3 bypass
•
The system supports 4 pairs of Generation 3 bypass to
allow continuous traffic flow even when the system
hangs. We offer a comprehensive suite to implement
this feature by programming. See appendix for more
information.
Refer to the chart below for a summary of the system’s
specifications.
Note: For instructions on quick installation and acquiring
the Intel® Communications Chipset 895x Series Software
(Coleto Creek) and the Intel® Communications Chipset
89xx Series Software (Cave Creek), refer to the attached
PDF file AV-ICE02 and AV-ICE01 respectively.
System Specification
Form Factor 1U Rackmount
Platform
Processor Options
2x Intel® Xeon® E5-2600
series on LGA2011/E5-2600
v2 series on LGA2011
Chipset Intel® DH8920/8950
BIOS
AMI BIOS
64MB SPI Flash ROM
System
Memory
Technology
Quad-channel DDR3
1066/1333/1600MHz
RDIMM or
UDIMM, Support ECC
Max. Capacity 128GB
Socket 16 x 240P DIMM
OS Support Linux kernel 2.6 or above
Storage
HDD Bays 1 x 2.5” SATA HDD
CompactFlash 1 x Type II CompactFlash
Networking
Ethernet Ports
14/10xGbE copper RJ45
ports and 6x10G SFP+
Bypass 2 pairs Gen 3
Controllers
1x Intel I347-AT4, 2x Intel
I350-AM4, 3x Intel 82599ES
Ethernet Modules N/A
Management Port 2 x GbE (RJ-45)
Security Accelera-
tion
Intel QuickAssist technology
I/O Inter-
face
Reset Button
Software programmable
reset button
Console 1 x RJ45
USB 2 x USB 2.0
IPMI via OPMA slot Optional
Expansion
PCIe
2 x PCI-E*16 through by ZD
connector reserved for the
custom model in 2U form
factor
PCI N/A
Cooling
Processor CPU heatsink with fan duct
System
4x independent hot-
swappable cooling fans with
smart fan control
Environ-
mental
Parameters
Temperature,
ambient operating /
storage
0 ~ 40º C / -20~70º C
Humidity (RH),
ambient operating
/ ambient non-
operating
5~90%, non-
condensing/5~95%, non-
condensing
Miscellane-
ous
LCD Module 128 x 64 Graphic LCM
Watchdog Yes
Internal RTC with Li
Battery
Yes
