-9-
Key Description Part Number
11 Piston Ring, Graphite,
Design ED Only
Non-Oxidizing Service 10A3262X012
Oxidizing Service 10A3262X022
13
Cage
Equal Percent-
age
17-PH SST 20A3245X012
316 SST Ni Coated 20A5467X012
316 SST CR PL 20A4348X012
Linear 17-PH SST 20A3247X012
316 SST Ni Coated 20A5468X012
316 SST CR PL 20A4349X012
Quick Opening 17-PH SST 20A3249X012
316 SST Ni Coated 20A5469X012
316 SST CR PL 20A4350X012
14 Seat Ring,
Gasket,
Metal Seat
Metal Seat -425 o F to 800 o F (-254 o C to 427 o C), material 10A3266X012
-425 o F to 800 o F (-254 o C to 427 o C), material 10A3266X022
Composition Seat, Nitrile 10A3266X032
15 Pipe Plug Steel (LCC & WCB Bodies) 1A771528992
316 SST (316 SST Bodies) 1A771535072
16 Drive Screw (2 req’d), CD PL Steel 1A368228982
17 Disc Retainer, 316 SST, Composition Seats Only 10A4466X012
18 Disc Seat, 316, Composition Seats Only 20A4467X012
19 Seal Ring, TFE, Spring Loaded, -100 o F to 450 o F (-73 o C to 232 o C), Design ET Only 10A3261X012
20 Disc, TFE, -70 o F to 400 o F (-57 o C to 204 o C), Composition Seats Only 20A4468X012
21
Packing
Ring
Graphite (2
req’d)
3/4” Stem (19.1 mm) 1D749001052
1” Stem (25.4 mm) 1D751801052
TFE (8 req’d) 3/4” Stem (19.1 mm) 1E319101042
1” Stem (25.4 mm) 1D7518X0012
Laminated
Graphite (4
req’d)
3/4” Stem (19.1 mm) 1V239601652
1” Stem (25.4 mm) 1U676801652
22 Bonnet See Following Table
23 Pipe Plug (Tapped Extension
Bonnets Only)
Steel (Steel Bonnets) 1A767524662
316 SST (316 SST Bonnets) 1A767535072
24 Spring, 316 SST
(TFE V-Ring Packing Only)
3/4” Stem (19.1 mm) 1F125637012
1” Stem (25.4 mm) 1D582937012
Lantern Ring, 316 SST
(Laminated Graphite Pack-
ing, 2 req’d, Other Packing,
1 req’d)
3/4” Stem (19.1 mm) 0N028435072
1” Stem (25.4 mm) 0U099735072
25 Special Washer, 316 SST
(TFE V-Ring Packing Only)
3/4” Stem (19.1 mm) 1F125036042
1” Stem (25.4 mm) 1H982236042
Parts Reference
