Key 2: Valve Body
End Connection Steel (LCC) Steel (WCB) 316 SST
Without Drain Plug Tapping
RF Flg
150 lb 30A3224LX012 30A3224WX012 30A3224X062
300 lb 30A3225LX012 30A3225WX012 30A3225X062
600 lb 30A3226LX012 30A3226WX012 30A3226X062
RTJ Flg
150 lb 30A3227LX012 30A3227WX012 30A3227X062
300 lb 30A3228LX012 30A3228WX012 30A3228X062
600 lb 30A3229LX012 30A3229WX012 30A3229X062
Butt Weld Sch 40 30A3222LX012 30A3222WX012 30A3222X062
Sch 80 30A3223LX012 30A3223WX012 30A3223X062
With Drain Plug Tapping
RF Flg
150 lb 30A3232LX012 30A3232WX012 30A3232X062
300 lb 30A3233LX012 30A3233WX012 30A3233X062
600 lb 30A3234LX012 30A3234WX012 30A3234X062
RTJ Flg
150 lb 30A3235LX012 30A3235WX012 30A3235X062
300 lb 30A3236LX012 30A3236WX012 30A3236X062
600 lb 30A3237LX012 30A3237WX012 30A3237X062
Butt Weld Sch 40 30A3230LX012 30A3230WX012 30A3230X062
Sch 80 30A3231LX012 30A3231WX012 30A3231X062
Key 2: Valve Body
Stem Size Valve Stem Connection Material
in mm in mm 416 SST
Hardened
316 SST
316 SST
Hard Faced Seat
& Guide
3/4 19.1 3/4 19.1 21A5356X012 21A5356X022 21A5362X012
1 25.4 1 25.4 21A5356X012 21A5357X022 21A5363X012
Key 22 Bonnet, Same material as body
Material Style
3-9/16” Yoke Boss
3/4” Stem
5” Yoke Boss
1” Stem
Steel
Plain 30A5471X012 ---
Style 1 Extension Tapped 30A3279X012 30A3280X012
Untapped 30A3270X012 30A3274X012
316 SST Style 1 Extension Tapped 30A3279X062 30A3280X062
Untapped 30A3270X062 30A3274X062
