5 Router config H8951 3G/4G Router
(2014-07-01) - 104 -
Parameter Details Operation
IP Address To show the external network IP address which the router
links
DNS To show which DNS router is using
SIM Status Status of current SIM
5.8.6 Routing Table
Step 1 Log-on WEB GUI of H8951 3G/4G router.
Step 2 Click “Status > Routing Table” to open “Routing Table” tab.
Figure 5-83 Routing table page
Table 5-44 Routing table Parameter instruction
Parameter Details Operation
Static route
Network IP address the router can reach
Subnet Mask IP network the router can reach. It is used together
with “Network”
Gateway Next hop IP address which the router will reach
interface Interface from router to gateway
metric Route No which the router reaches destination IP
Policy route
