SMA Solar Technology AG Appendix B
Installation Guide SC-100-IEN093231 45
10.2 Technical Data SC 100 indoor
Sunny Central data Symbol SC 100 indoor
Input data
Max. PV power (recommended) P
PV
110 kWp
a)
DC voltage range, MPPT U
DC
450 - 820 V
Max. permissible DC voltage U
DC, max
900 V / optional 1000 V
Max. permissible DC current I
DC, max
235 A
Voltage ripple, PV voltage U
PP
< 3 %
Number of DC inputs / terminal not secured 3 x positive (120 mm²)
M12 screws
3 x negative (120 mm²)
M12 screws
Output data
Nominal AC output power P
AC
100 kW
Operating grid voltage +/- 10 % U
AC
400 V
Nominal AC current I
ACnom
145 A
Grid structure TT, TN-S, TN-C grid
Operating grid frequency f
AC
50 Hz - 60 Hz
Harmonic distortion of grid current K
IAC
< 3 % at nominal power
output
Power factor
cos ϕ
≥ 0.99 at nominal power
output
Efficiency
per IEC61683
10 % ; 25 % ; 50 % ; 75 % ; 100 %
of P
ACnom
η
10, 25, 50, 75, 100
94.2 / 96.4 / 96.7 /
96.4 / 96.2 %
Euro ETA η
euro
96.2 %
Dimensions and weight
Width x Height x Depth [mm] W/H/D 1270 / 1610 / 805
Weight (approx.) m 925 kg
