Installation Guide
6.2 Electrical installation
The complete wiring for a Sunny Boy SB 1100LV is shown schematically in the following
diagram:
* Circuit breaker according to DIN VDE 0100-712
Attention!
Make sure to check the polarity of the strings before connecting them!
Communication
max. 2.5 mm²
String
Circuit
