4-14 HD video mode Viper
ND/RE BATT TAPE REC ++ + -
AW2 AW1 FL 7.5 5.6 3.2
FOC+
4.7 !
Viewfinder Indicators
Gain indicators
The gain indicators along the top of the viewfinder light as follows:
- Gain is - (-3 or -6dB)
+ Gain is + (3, 6 or 9dB)
++ Gain is ++ (6, 9 or 12dB)
+ and ++ Gain is +++ (12, 15 or 18dB)
8
2
3
4
5
6
7
1
9
10
11
1
