Pci interconnect board removal, To figure 10 to, Figure 10 – Grass Valley Profile Family 18GB Disk Drive Upgrade User Manual
Page 35
Installing the SCSI Cable in Systems with a New Slave EDR
18GB Disk Drive Upgrade
35
Figure 10. PCI Interconnect Board Removal
7. Dress the SCSI cables through the channel to the right of the Fan Carrier
Tray.
8. Now that you have installed the SCSI cable, proceed to “Installing Disk
0563-7
Slave EDR Board
Master EDR Board
Alignment Keys
PCI Interconnect
Board
SCSI A Connector
SCSI C Connector
