41
IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING
CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED.
ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR
DUE TO UNSAFE INSTALLATION OR USAGE OF THIS PRODUCT. CALL TECHNICAL SUPPORT WITH QUESTIONS.
REPLACEMENT PARTS LIST
Part Number Part Description Diagram #
Gaskets
PU‐HLG Hopper Lid Gasket 1
AC‐DGKNC 5/8” Door Gasket 2
AC‐GGK Window Gasket Kit 3
PU‐CBG Exhaust Blower Gasket 4
AC‐GGK Ash Pan Gasket 5
PU‐CGEP Cradle Mating Gasket 6
Electrical Components
PU‐CHA Igniter Cartridge Heater 7
PU‐076002B Exhaust Blower 8
PU‐4C447 Room Air Blower 9
AC‐HLSB Hopper Lid Switch 10
CU‐VS .05" of WC Vacuum Sensor 11
CU‐047042 2 RPM Auger Motor 12
PAH‐CB09 Control Board 13
Cast Iron
CA‐AMPP Cast Iron Auger Motor Collar 14
CA‐13 Cast Iron Door 30
Steel
CA‐AC Steel Auger Coupler 15
PAH‐ECC Exhaust Cleanout Covers 16
PAH‐BPC Cradle 17
PAH‐BP Burnpot 18
PAH‐EBAD Combustion Blower Access Door 19
PAH‐BAD Convection Blower Access Door 20
PU‐AFEP Steel Auger 21
AC‐GS13 Glass Support Brackets 22
PAH‐RAP Rear Access Panel 23
PAH‐ECP Exhaust Outlet Cover Plate 24
PAH‐AWB Airwash Bar 25
PAH‐AP Ash Pan 26
Glass
AC‐G17 Window Glass 27
Misc
PU‐62‐40‐151‐3 Hopper Lid Latch 28
PU‐VH High Temp. Vacuum Hose Not Shown
CU‐RG Rubber Vibration Dampener 29
AC‐SHN Nickel Spring Handle Not Shown
AC‐SH Brass Spring Handle Not Shown
PU‐PGB52 Exhaust Tube Insulation Wrap (PDV) Not Shown
