Page 73
6 July 2004
M-Series Service Manual
73
Internal Parts Removal
Internal Parts Removal
The illustrations that follow show how to remove internal parts from the M-Series
iVDR.
CAUTION: To avoid possible damage to circuit boards and other
sensitive parts, turn off the iVDR and disconnect AC power before
opening the top cover or removing any internal parts.
Top cover removal
!
2
3
Remove
rear
screw
1
Remove
top
screw
Push back
1 cm to release,
then lift off
