Open kayakdd-2 panel, Figure 34, Kayakdd-2 control panel – Grass Valley KayakDD-2 v.6.7.1 User Manual
Page 86: Figure 35, Battery on the board of the control panel
KayakDD-2 Digital Production Switcher
7.4.9.2
Open KayakDD-2 Panel
1. Loosen the sixteen screws around the.
Figure 35
KayakDD-2 Control Panel
2. When all screws are loosened, lift the top of the panel carefully. The battery is
located in the middle of the base board
Figure 36
Battery on the Board of the Control Panel
Planning and Installation Manual
85
