KayakDD-2 Digital Production Switcher
Jack Designation Note
J45/J46
J47
J48
J49
M/E OUTPUTS
PGM
PVW-A
CLEAN
CLEAN PVW
BNC / Serial Comp (ITU-R 656)
Double Program output
Preview output
Clean output
Clean Preview output
J4/J5
J6
J7
J8
P/P OUTPUTS
PGM
PVW-A
CLEAN
CLEAN PVW
BNC / Serial Comp (ITU-R 656)
Double Program output
Preview output
Clean output
Clean Preview output
J9
:
J18
AUX 1 – AUX10 Auxiliary Outputs, BNC / Serial Comp (ITU-R 656)
J41
J42 REFERENCE Reference input, BNC / 75 ohms
Loop through sync input for analog Blackburst or
CCVS signal.
J19
:
J24
RS 485 PORTS Six control ports, 9-pin D-type female
RS485 serial ports for devices such as DVEs, Editors,
Routers and for Machine Control (Disk Servers, VTR).
J43 GPI/O - TALLY 50-pin D-type female
General-purpose interface connector with 8 input
channels and 32 output channels.
The connector is used for Tally also.
Refer table below for respective pin assignment.
J44 LAN RJ45 connector for connection to the Control Panel.
An interconnecting cable with a length of 10 m is
enclosed. Cables with lengths of 20m or 50m can be
ordered optionally.
