KayakDD-2 Digital Production Switcher

Jack Designation

Note

DC POWER IN

Input connector for external DC Power Supply Unit
(KDD-PSU) for redundancy (High current D-Sub,
female).

Input voltage: 48V/ 5A

Note:
The external power supply unit must comply with
the SELV (Safety Extra Low Voltage) standard
exclusively. ELV and TNV standard is not
permitted!

Additionally the 8V DC voltage for RAM Recorder
buffering can be supplied via this socket.

Refer table below for respective pin assignment.

DC POWER
OUT

Output connector for Panel DC Power Supply.
(High current D-Sub, male).

Output voltage: 48V/ 1.6A max

An DC power interconnecting cable with a length of
10 m is enclosed.
