16
Kaleido-RCP2
Resetting the Kaleido-RCP2
• All other keys on the Kaleido-RCP2 are disabled (LEDs off ).
• The LCD display is off.
• Any peripherals (e.g. mouse, keyboard) connected to the Kaleido-RCP2's USB ports are
also disabled.
The purpose of the panel enable function is to lock the user interface of the remote, thus
avoiding any accidental access to the Kaleido system.
Resetting the Kaleido-RCP2
To reset the Kaleido-RCP2
• Press ENTER + ESC + DEL simultaneously to restart the device.
• Disconnect and reconnect the Kaleido-RCP2's Ethernet cable to power cycle the device.
• The device will be reset automatically in case of software or hardware failure of its
internal controller.
Specifications
Ethernet port
Signal 100/10 BASE-T, (IEEE 802.3AF)
Connector RJ-45 with LED and 48 V power
USB ports
Signal USB 2.0 (for low speed HID devices only, compatible with 1.1)
Connector 2 USB host connectors (mouse and keyboard only)
Dimensions 78 mm × 203 mm × 32 mm (3.5 in × 8 in × 1 in)
Voltage 48 V
Power 5 W Max for RCP2 itself + 5 W Max for USB Devices
Miscellaneous
Operating temperature range (ambient) 5–40°C (41–104°F)
