9
Kaleido-MX (3RU)
Hardware Description & Installation Manual
• Two WECO mating connectors for each output card (as per order), for the analog audio
monitoring outputs, plus one for the CPU-ETH2 controller card’s GPI output:
• Two serial port adapters (one with straight cabling and one with crossover cabling
—
see
The Kaleido-MX (3RU) 32 × 4, 48 × 4, and 64 × 4 models include a second pair of serial
port adapters.
• The Kaleido-MX (3RU) Quick Start Guide
• DVD including the Release Notes for the current version of the Kaleido-X software, the
Kaleido-X User’s Manual, database samples, Quick Start guides and hardware reference
manuals for all multiviewer models
3RU model
WECO connectors
32 × 2
3
32 × 4
5
48 × 2
3
48 × 4
5
64 × 2
3
64 × 4
5
Part number
Adapter cabling
RS-422 pinout at the DE-9P connector
1737-3000-102
Straight
Controller (SMPTE master) mode
1792-3700-100
Crossover
Tributary (SMPTE slave) mode
Note:
In line with our commitment to environmental preservation, only the
Quick Start Guide for your multiviewer model, and some ancillary
documents (e.g. welcome letters, warranty cards) are distributed in printed
form. All manuals and the Release Notes are available on the DVD that
shipped with your multiviewer. See the Documentation section of the
Release Notes for a complete list. You can obtain the latest version of the
manuals, the Release Notes, as well as software and useful data, from the
Documentation Library section of Grass Valley’s website.
