1
Installation
The Kaleido-MX multiviewer system is ideal for production control rooms, trucks and
outside broadcast operations.
Introduction
Available in two form factors (1 RU, and 3 RU), the Kaleido-MX supports up to 64 video
inputs. Pre-configured Kaleido-MX systems are available in the following sizes:
Features
Frame Inputs × outputs
Kaleido-MX (1RU) frame
8 × 1, 8 × 2,
16 × 1, 16 × 2,
16 × 4, 24 × 1,
and 24 × 2
Kaleido-MX (3RU) frame
32 × 2, 32 × 4,
48 × 2, 48 × 4,
64 × 2, and
64 × 4
Kaleido-MX features
Unmatched
image quality The Kaleido-MX offers unmatched image quality and superior on-screen
graphics, with simultaneous HDMI and SDI outputs at full 1080p 50/60
Hz
resolution on up to four multiviewer displays.
Robust and
serviceable
design Its auto-recovery feature provides fast automated recovery after a cold spare
is inserted into the frame.
Hot-swappable modules and power supplies.
1
RU and 3 RU frame models with quiet cooling.
Multi-room,
multi-user
oriented A single Kaleido-MX multiviewer can be used to share sources across
multiple rooms or operator positions, with fully independent displays, audio
monitoring and control panels dedicated to each operator.
