Grass Valley Kaleido-IP v.6.02 - Manual (Page 25)

Kaleido-IP
Quick Start Guide
21
Java Setup will update your PC or laptop.
5. Click Close once the installation has completed.
Step 4: System Setup
Before you can proceed with monitor wall operation, you must use XEdit to add transport streams to your
Kaleido-IP system configuration, define logical sources based on the signals your wish to monitor,
configure monitor wall destinations (if desired), and configure the required rooms and layouts for your
purposes. Although it is possible to partly configure your system by using XEdit in offline mode, you may
initially prefer to work in online mode, to take advantage of the predefined room and layouts that are
available in the default configuration.
Opening XEdit in Online Mode
To open XEdit in online mode:
1. From a workstation on the same subnet as the multi-viewer, open a Web browser window and enter
the management IP address of your Kaleido-IP multi-viewer in the address bar.
The Kaleido-X home page appears.
2. Click the XEdit button.
3. When prompted to specify a database, choose one from the Path list, or click Browse to specify
another location, and then click OK to continue.
The main application window appears.
