12
Setting Up the Kaleido-IP Multi-Viewer
Finding the Management IP Address and Application Version 2
Finding the Management IP Address and Application Version
To find the management IP address and application version:
1. Connect a mouse to a USB connector: either at the front of the frame, or on the rear panel.
2. Right-click anywhere on the monitor wall. On the shortcut menu, point to Monitor Wall (if you clicked
a monitor), and then click Show dashboard to display the dashboard associated with the current
head. A small window appears in the bottom-right area, revealing the management IP address and
the system version. Take note of these values.
Configuring a Client PC
The client PC that you will use to communicate with the Kaleido-IP multi-viewer (via XAdmin and XEdit)
and the multi-viewer’s gigabit Ethernet port associated with the management network must have IP
addresses within the same subnet. The following procedure applies to a typical Windows XP system. For
Windows 7, see “Changing an IP Address on Windows 7” on page 13.
Changing an IP Address on Windows XP
To change the IP address of a client PC that has Windows XP:
1. On the Start menu, point to Control Panel, right-click Network Connections, and then click Open on
the shortcut menu.
2. In Network Connections, right-click Local Area Connection, and then click Properties on the
shortcut menu.
3. In Local Area connection Properties, select Internet Protocol (TCP/IP) from the list on the General
tab, and then click Properties.
The Internet Protocol (TCP/IP) Properties window opens.
Application version
Management IP address
System name Room name
