H
ard
w
are S
pe
cifi
ca
tio
ns
EDIUS SD (RX-E1)
Video Format
Input /
Output
Signal
Format
SD-Mode
SDI 10bit (SMTPE 259M-C
Compatible)
Spported
Formats
SD-Mode
720 x 486 (NTSC) or 720 x 576
(PAL)
Internal Signal
Processing Format 4:2:2 input / Output 10bit
(Internal processing 8bit)
Video
Input
Terminal
SD-SDI BNC x 1
SD Ref
BNC x 1
(Black Burst Signal, 75 ohm)
Output
Terminal
SD-SDI BNC x 2
Audio
Input
Terminal Embedded
Audio BNC x 1 (SMPTE 299M / 272M-
A Compatible)
Output
Terminal
Embedded
Audio BNC x 1 (SMPTE 299M / 272M-
A Compatible)
Analog
Monitor LINE OUT x 1
(Output from a Sound Card)
Audio Format Embedded Audio
SMPTE 299M / 272M-A
Compatible
Control
Terminal
Remote Control RS-422A D-sub 9pin x 1
