Grass Valley EDIUS 5 User Manual
Page 21
19
H
ard
w
are S
ett
in
g
Attaching the Dongle (to the HD board)
Notes
Attaching the HDBX-1000H to EDIUS-HD
V26 Dongle
HDRX-E1 board with V26 Dongle
•
1
Attach the dongle (V26 Dongle) to the HD board and fasten it
with the screw.
* Please pay attention to the connector direction and insert it in the center.
Attaching location
After
