Page 15: Setting the sdi bracket setting the sub board
13
H
ard
w
are S
ett
in
g
Setting the SDI bracket
1
Connect main board and SDI bracket.
SDI-IN
SDI-OUT1
SDI-OUT2
Main board
Setting the Sub Board
Expansion board (HX-HD1)
1
Tightly slide expansion board (HX-HD1) in PCI slot and fix
the bracket temporarily.
2
Connect main and expansion boards with the board
connection cable (6pin-6pin).
Main board
Expansion board (HX-HD1)
Board connection cable (6pin-6pin)
