Sonata Series — Planning and Installation Manual 64
MADI
MADI
Table 30. Inputs
Table 31. Outputs
Reference
Table 32. Video Reference
Table 33. Audio Reference
Connectors Coaxial via BNC 75-ohm according to AES10-1991
Input Return Loss >20 dB 100 kHz to 125 MHz
Maximum Cable Lengths Up to 300 feet (100 meters)
Nominal Input Level 500 mV p-p.
Modes supported @ 44.1 kHz & 48
kHz sample rate 64-channel mode standard.
56-channel mode via DIP switch option.
Modes supported @ 88.2 kHz & 96
kHz sample rate 32-channels in.
Connectors 75-ohm terminating BNC 2 ea. provided.
Output Return Loss > 15 dB.
Video
Connectors Loop-through 75-ohm BNC.
Return Loss >40 dB to 5 MHz.
Reference Selection Automatic between video black and Tri-level.
Video Standards Supported Automatically detects and locks to:
480i59
575i50
1080i59
1080i50
720p59
720p50
Sample rate when locked to video ref-
erence Provides a 48 kHz sample rate according to AES11-1997.
Audio
Connectors Loop-through 75-ohm BNC.
Return Loss > 25 dB 100kHz to 12 MHz.
