Sonata Series — Planning and Installation Manual

54

Table 14. 110M Connector D Pinouts

Sonata Input

Connector D Pinout

Notes

25 Plus

24

25 Minus

12

25 Ground

25

26 Plus

10

26 Minus

23

26 Ground

11

27 Plus

21

27 Minus

9

27 Ground

22

28 Plus

7

28 Minus

20

28 Ground

8

29 Plus

18

29 Minus

6

29 Ground

19

30 Plus

4

30 Minus

17

30 Ground

5

31 Plus

15

31 Minus

3

31 Ground

16

32 Plus

1

32 Minus

14

32 Ground

2
